Magnetic Axis Switch High Performance RT Accuracy 0.005 Magnetic Switch Mechanical Magnetic Shaft Keyboard Pre Lubed
Parameters of Tarzan Magnetic Axes
Housing: PC
Initial Gauss value: 100Gs
Shaft core: UPE mix
Bottom gauss value: 640Gs
Magnet: N pole down Magnet centred
Total stroke: 3.5mm
Initial pressure: 35gf
Spring length: 22mm
Bottom pressure: 47gf
Note
Adaptation can be calibrated by selecting a magnetic axis preset within the driver. Procedure:Unplug the data cable - Replace the Tarzan magnetic axis - Insert the data cable - Open the driver to select a magnetic axis preset (Magneto RGB is recommended) - Button press to touch the bottom to knead for 2 seconds to calibrate, and you can use it after success.
Compatibility
Confirm the product type, interface and specifications match your keyboard before ordering.
Product support
Questions about fit or specifications? Email support@cuxiukeys.com with your keyboard model.
